Aluminum Rear Lower Front Suspension Arm Mount Arrma 1/8
Made by Hot Racing · AON09RF01
Parts lists
Description
- Secure M4 set screw to maintain hinge pin position under the most severe conditions
- CNC machined 6061 aluminum construction
- Two (2) M4 x 4mm
- Two (2) M3 x 10mm FH
- Recommended to use medium thread lock on screws
- Known to fit the following Arrma vehicle part numbers. The vehicle part number can be found on Arrma's website, the literature that came with the vehicle, or on the vehicle box around the barcode. If a vehicle is marked below with the word "optional, " then the part may fit, but may require some modification.
- InFraction ARA109001
- Kraton: AR106005, AR106015, AR106018, AR106029/31 (red/green), ARA106040T1/2 (red/blue)
- LimitLess ARA109011
- Notorious: AR106034/6 (black/blue), ARA106044T1/2 (black/blue)
- Outcast: AR106021, AR106027, AR106032/3 (silver/orange), ARA106042T1/2 (silv/org)
- Senton: AR106007, AR102654, AR102673
- Talion: AR106003, AR106014, AR106030 (2018 V3 model), ARA106048 (V4)
- Typhon: AR106001, AR106013, AR106028, ARA106046
description revised by: SN May 6, 2019
Manufacturer information
All warranties and guarantees, including missing items, are handled directly by the manufacturer of that item. Should there be any problem with a product, you (The Customer) will need to contact the manufacturer to obtain service. Manufacturer contact information is available upon request. We must be contacted for a return authorization number before returning items for any reason. We cannot accept returned items that have been opened or are not in their original sealed factory containers.
Compatible vehicles
Related parts
Additional details
| Country of origin | China |
| Package dimensions | 3.99" × 3.99" × 0.25" 10.13 cm × 10.13 cm × 0.64 cm |
| Part numbers | AON09LF01 AON09RF01 AOR09RF01 ANN09RF01 AONO9RFO1 840353307148 083745293784 HRAAON09RF01 |
| Shipping weight | 0.50 ounces 14.15 grams 0.03 pounds |
