Quicrun 3660sl G2 Motor; 3700kv

Hobbywing QuicRun 3660SL G2 Sensorless Brushless Motor, 3700kv (30404501) is a 1:10 scale 4-pole sensorless brushless motor rated for 2S to 3S LiPo, sized for trucks and monster trucks. The G2 version delivers about 10 percent more peak output and 8 percent better efficiency than the previous generation, which means it runs cooler under the same load. It uses a reinforced rotor with aluminum end plates and high-strength winding for burst resistance, a high-hardness aluminum can with CNC-machined end cover, 0.2mm low-loss silicon steel laminations, high-precision bearings, and 200 degree C rated windings, and the modular construction comes apart for cleaning and maintenance. The 3700kv is the middle option of the three G2 3660 motors, quicker than the 3150kv while keeping 3S capability that the 4500kv gives up. It pairs with the QuicRun WP 10BL120 G2 ESC or any sensorless-capable brushless ESC.
* 3660 size, 36mm diameter, 60mm length
* 3700kv, 2S to 3S LiPo
* 5mm shaft diameter, 18.5mm shaft length
* 4-pole sensorless design
* 10 percent more maximum output and 8 percent higher efficiency than the previous generation
* Reinforced rotor with aluminum end plates and high-strength winding
* High-hardness aluminum can with CNC-machined end cover
* 0.2mm ultra-thin low-loss silicon steel laminations
* High-precision bearings, 16x5x5mm front and 13x5x4mm rear
* 200 degree C high-temperature enameled wire
* High-current silicone wires with 4.0mm male bullet connectors
* Modular, detachable design for cleaning and repair
* Weight 278g
* For 1:10 truck and monster truck applications
* Also available in 3150kv (30404500, 2-3S) and 4500kv (30404502, 2S)
* 1 x QuicRun 3660SL G2 brushless motor, 3700kv, with wires and bullet connectors installed
* Sensorless-compatible brushless ESC rated for the motor (Hobbywing QuicRun WP 10BL120 G2 recommended)
* 2S or 3S LiPo battery
* Female 4.0mm bullet connectors on the ESC side, or matching adapters
* Pinion gear for a 5mm motor shaft
* Motor mounting screws
* Vehicle with a 3600-size motor mount
