2300kv Roc412 Element Proof Rock Crawler brushless Motor

Tekin's Element Proof ROC412 offers protection from the elements, giving you the power to take on the trails or track without fear of water, mud or snow! Designed for heavier trail or rock racing rigs, the ROC412 delivers more torque and more power on demand. Using a 4-pole 12-slot motor design, the ROC412 harnesses the benefits of brushless efficiency and extreme amounts of torque to stay on the trail longer with more power. Couple the ROC412 with an RX4 or RS GEN2 speed control for the smoothest brushless crawling system available. Rock Racing power and Crawling precision are at your disposal
- Element Proof design tackles Water, Mud and Snow
- Crawler, Rock Race and Trail Rig Specific
- 4 Pole 12 Slot High Torque Motor Design
- 18.5mm Rotor provides superior Torque and Braking Power
- CNC Machined 6061-T6 Billet Aluminum Heat Sink Can
- Neodymium Sintered Magnets
- Precision Engineered for Maximum Energy Conversion
- High Purity Copper Windings Maximize Conductivity and Efficiency
- Low Resistance, High Power Solder Tabs
- Dual-Plug Sensor Wire Harness for all Sensored and Sensorless systems
- Anodized End-bell plates maximize corrosion and wear resistance
- High RPM ABEC-5 Precision Bearings
- Oversized Front Bearing adds Durability
- Rebuild-able Design
- One (1) 2300kV ROC412 Element Proof Rock Crawler brushless Motor
- Voltage Limit: 5700kV - 2S LiPo; 4600kV - 2S LiPo; 3100kV - 3S LiPo; 2300kV - 4S LiPo; 1800kV - 4S LiPo; 1200kV - 6S LiPo; 500kV - 6S LiPo
- Weight: 6.3oz / 179g
- Shaft size: 3.2mm (1/8 inch) x 15.3mm
- Motor diameter: 35.85mm / 1.40 inch
- Motor length: 52.5mm / 2.10 inch
- Front bearings: 5x14x5mm
- Rear bearings: 5x11x5mm
- Rotor Size: 18.5mm
- Rebuildable: Yes
- Element Proof ESCs and Motors are specially designed to withstand water splashes and are not meant to be submerged. Included dielectric grease must be used on the sensor and fan port connections to protect them from shorting.
- The ROC412 EP is not intended for operation while submerged in liquid.
- Anytime your motor sees water it is important that you perform the proper after run maintenance. Warranty does not cover neglect, lack of maintenance, bearings, rust or any damage that may occur if the motor is submerged in water.
description revised by: SN October 22, 2019
